Elastomer Socket
Our latest elastomer socket innovation introduces Nano-Block Technology (NBT) – block-shaped conductive particles integrated within an advanced elastomer structure, designed to redefine precision connectivity for semiconductor testing. This new block particle architecture delivers superior performance through a solid block-like connection, enhancing durability and electrical stability.
Why choose elastomer socket?
Traditional Method
Conventional Particle
The contact surface between particles is small
– It is easy to be defective by physical impact
New Technology
Nano Block Technology (NBT)
The contact surface is relatively large.
– Reduced contact resistance
– Structure with reinforced bonding between particles
– Strong against physical impact
Product Specification
Single Layer (SL)
0.35mm ~ 0.80mm
Available Pitch
0.35mm ~ 0.70mm
Thickness
0.10nH ~ 0.19nH
Inductance @ 1GHz
0.04pF ~ 0.07pF
Capacitance @ 1GHz
Heavy Layer (HL)
0.50mm ~ 0.65mm
Available Pitch
0.70mm ~ 0.90mm
Thickness
0.20nH ~ 0.30nH
Inductance @ 1GHz
0.08pF ~ 0.11pF
Capacitance @ 1GHz
Double Layer (DL)
80mm
Available Pitch
0.80mm
Thickness
0.37nH
Inductance @ 1GHz
0.13pF
Capacitance @ 1GHz
Product Detail
