Zip40 Charging and Management Cart, UK

• GTIN: 00698833076028
• Part Number: DM40-2008-3
• Product Weight: 85.6 kg
• Shipping Weight: 106.5 kg
• Shipping Dimensions: 37″ x 30″ x 52″ (94 x 75 x 132 cm)
• Product Dimensions: 32.4″ x 26.2″ x 44.3″ (82.2 x 66.4 x 112.5 cm)
• Description: Zip40 Charging and Management Cart (grey/white)
• Includes 40 dividers, 9 small device divider stoppers, 9.8′ (3 m) country-specific power cord, 4 country-specific 10-outlet power strips, two 20-unit brick storage trays, four 5″ dual-wheel locking casters, external auxiliary outlet (2 receptacles in US, JP or 1 receptacle in EU, UK, AU, CN), 2 mounting brackets for Ethernet switch, 2 internal auxiliary outlets for Ethernet switch and WAP installation, power on/off switch, 2 keys, 40 CAT6 Ethernet cables, 3 Ethernet cable storage trays, one 19′ (5.9 m) CAT6 Ethernet cable, Velcro cable management straps
• Ships fully assembled
• Total Capacity: Up to 40 devices with 1.1″-wide (28 mm) slot; up to 30 devices with 1.9″-wide (48 mm) slot
• Maximum device dimensions: 17.1″W x 11.2″H (43.4 x 28.4 cm) including case and cord. Screen size may exceed 15.6″ if the device’s outside dimensions fit within these measurements
• Divider bumpers shorten the slot size to provide easy plug-in access for smaller tablet devices
• Maximum adapter dimensions: Brick-style AC adapter = 7″H x 3″W x 2.2″D (17.8 x 7.6 x 5.6 cm). Wall-plug-style AC adapter = 2.2″W x 4.7″L x 3.9″D (5.5 x 12 x 10 cm) including cable strain relief. Cable diameter = 2.6–4.6 mm
• Compatible with Apple’s eighth-generation iPad
• Weight capacity: Total = 255 lbs (116 kg); 76.5 lbs (34.7 kg) per shelf (3 shelves total in cart); 25 lbs (11.3 kg) top worksurface. Per device maximum weight of 7.6 lbs (3.4 kg) assumes 10 devices per shelf in a cart configured to hold 30 devices in total
• Country-specific 10-receptacle outlet strip is designed to work with oversized wall-style and brick-style AC adapters
• Uses the AC adapters that come with each device. AC adapters are not included
• Cooling/Ventilation: Four 12V DC continuous operation fans and ventilated doors keep equipment cool
• External Auxiliary Outlet(s) give you an always-on outlet to plug in extra peripherals like printers or document cameras. No need to choose between using the auxiliary outlets and charging devices—do both at the same time!
• Location included for installation of a Wireless Access Point (WAP not included). Maximum dimensions of the WAP = 10″W x 10″D x 2.2″H (25.4 x 25.4 x 5.6 cm)
• Location included for installation of a standard 1U rack mountable Ethernet Switch (switch not included). Maximum dimensions of the switch = 17.5″W x 12.4″D x 1.8″H (44.5 x 31.5 x 4.6 cm. Maximum weight of the switch = 12 lbs (5.4 kg)
• Country-specific power cord =12.5′ (3.8 m) long; stored on a recessed cord wrap
• Environmentally clean: RoHS, REACH, WEEE and EU (94/620EC) packaging compliant
• Power System: input/output = 100-240V~, 12-10A, 50/60 Hz
• Temperature Range: operating 0° to 30°C (32° to 86°F); storage -40°C to 60°C (-40° to 140°F)
• Relative Humidity (maximum): operating 10 to 90% (non-condensing); storage 5% to 95% (non-condensing)
• Altitude (maximum): 2000 m (6,562′)

Certification

• UL/IEC 62368-1 and CSA C22 2 No. 62368-1 for Safety of Information Technology Equipment; UL 1678 Household, Commercial, and Institutional-Use Carts, Stands, and Entertainment Centers for Use with Audio and/or Video Equipment
• ICES-003 Issue 4, Class A
• FCC Part 15 Class
• RoHS and Reach compliant material used

Warranty: Limited lifetime for the frame; five years for other mechanical components; three years for electrical components; one year for cables
